| Category | Descriptions | ||
| Model | S1B5S | Remark | |
| Input Power | DC 24V (±5%) | ||
| Power Consumption | Max. 12W | ||
| Current Consumption | Max. 500mA | DC 24V | |
| Ion-Generation Method | Corona Discharge Pulse AC | ||
| Air Purge Supply Pressure | 0.1MPa ~ 0.5 MPa | CDA (Clean Dry Air), N2 | |
| Air Purge Connection Port | Pipe Thread 1/8” | ||
| Ion Balance | within ±30V | 1,000mm | |
| Operating Distance | 50mm ~ 2,000mm | ||
| Operation Circumstance | 0°C ~ +50°C (32°F ~ 122°F), 35% ~ 85% RH | ||
| Ozone (O3) Concentration | ≤0.05ppm | ||
| Main Body Material | Non-Flammable ABS | Level V0 | |
| Electrode Material | Standard | Tungsten | |
| Option | Titanium, Poly Silicon | ||
| Electrode Replacement | Cartridge type | ||
| Mounting Method | Bolt Mounting with Bracket | ||
| Adjust Function | Frequency [Hz] | 1, 3, 5, 8, 10, 20, 30~100 | |
| Duty Ratio [%] | – | ||
| Voltage [Level] | 1 ~ 10 | ||
| Alarm Function | High Voltage Abnormal Alarm | ||
| Interface | Run State, Remote, RS485 | ||
Cleanroom Products, Equipment and Tools
Ion Bar (SIB5S Series)
Features
- Ion balance : +/- 30
- Stable ion balance during long term usage
- Low peak voltage through high frequency
- Increase ion generation by reducing corona discharge loss
- Tip cleaning alarm (You can set tip cleaning period with timer)
