Heel Grounder
 |
Part Number | ES-M13-Z-000 |
| Color | Black/White | |
| Ribbon | 18’’/30” long nylon/polyester tab with 8 conductive strands | |
| Resistor | 1 Mohm | |
| Cross-Linked tire grade rubberstrands | ||
| Type D | Type S |
| Two soles for double life span | One sole and an elastic back strap |
 |
 |
Selection Guide ( Heel, Toe and Sole Grounders )
| Part Number | Closure Styles |
Velcro (W) |
Elastic Velcro(W) |
Elastic Strap(W) |
Elastic Band(W) |
Size | Ribbon (L) |
Sole | |
| Heel Grounder (D) | ES-M13-Z-001 | HE | 3/4”(BK) | free size | 18” | double | |||
| ES-M13-Z-002 | HE | 3/4”(BL) | |||||||
| ES-M13-Z-003 | HE | 3/4”(GR) | |||||||
| ES-M13-Z-004 | HL | 3/4”(BK) | |||||||
| ES-M13-Z-005 | HL | 3/4”(BL) | |||||||
| ES-M13-Z-006 | DR | 3/4”(BK) | |||||||
| ES-M13-Z-007 | DR | 3/4”(BL) | |||||||
| ES-M13-Z-008 | QB | 3/4”(BK) | |||||||
| Heel Grounder (S) | ES-M13-Z-500 | HE | 3/4”(BK) | 1”(BK) | free size | 18” | Single | ||
| ES-M13-Z-501 | HE | 3/4”(BK) | 1”(RE) | ||||||
| ES-M13-Z-502 | HE | 3/4”(BK) | 1”(GR) | ||||||
| ES-M13-Z-503 | HE | 3/4”(GR) | 1”(BK) | ||||||
| ES-M13-Z-504 | HE | 3/4”(GR) | 1”(RE) | ||||||
| ES-M13-Z-505 | HE | 3/4”(GR) | 1”(GR) | ||||||
| ES-M13-Z-506 | HL | 3/4”(BK) | 1”(BK) | ||||||
| ES-M13-Z-507 | HL | 3/4”(BK) | 1”(RE) | ||||||
| ES-M13-Z-508 | DR | 3/4”(BK) | 1”(BK) | ||||||
| ES-M13-Z-509 | DR | 3/4”(BL) | 1”(BK) | ||||||
| ES-M13-Z-510 | QB | 1”(BK) | 3/4”(BK) |
Toe Grounder
Toe grounder with a snap-lock fastening system is designed for using with the variety of shoes, including high heels, cowboy boots, flats shoes, loafers and safety shoes.
 |
Part Number | ES-M14-Z-000 |
| Color | Black/White | |
| Ribbon | 12” long nylon/polyester grounding tab with 8 conductive strands | |
| Resistor | 1 Mohm | |
| Connecting with plug or snap button | ||
Selection Guide ( Heel, Toe and Sole Grounders )
| Part Number | Closure Styles |
Velcro (W) |
Elastic Velcro(W) |
Elastic Strap(W) |
Elastic Band(W) |
Size | Ribbon (L) |
Sole | |
| Toe Grounder | ES-M14-Z-001 | QB | 3/4”(BK) | 3/4”(BK) | free size | 12” | Single |
Sole Grounder
Sole Grounder is equipped with an elastic D-ring fastening system, which provides the snug cinching of ankle strap and allows “flex” during walking. They combine the features of heel and toe grounders and are designed to use most types of shoes and boots.
|
|
Part Number | ES-M15-Z-000 |
| Color | Black/White | |
| Ribbon | 12” long nylon/polyester grounding tab with 8 conductive strands | |
| Resistor | 1 Mohm | |
| Connecting with plug or snap button | ||
Selection Guide ( Heel, Toe and Sole Grounders )
| Part number | Closure Styles |
Velcro (W) |
Elastic Velcro (W) |
Elastic Strap (W) |
Elastic Band (W) |
Size | Ribbon (L) | Sole | |
| Sole Grounder | ES-M15-Z-001 | HE | 3/4”(BK) | 3/4”(BK) | S | 12” | Single | ||
| ES-M15-Z-002 | HE | M | |||||||
| ES-M15-Z-003 | HE | X | |||||||
| ES-M15-Z-004 | HE | XL |
Closure Styles
